HAWK 8200S

Multi-Purpose Single Cartridge Bond Test System
The next-generation bond tester HAWK-8200S model, which was created based on the field application technology of the 8000 Single bond tester for a long time, provides users with the best work convenience and efficiency, and realizes the best test quality with optimal user-friendly functions and ergonomic desktop equipment. did. Slim, ergonomic design through integrated development of one board control system

One touch position control microscope holder considering various workers
Various size stage options that can be converted by easy attachment/detachment, 50×50, 100×100, 200×200, customized type
High load , Electromagnet Clamping Shear Cartridge System for precise control
> Significantly improved workability with 350mm work fixture plate Cartridge replaceable tester suitable for repeated tests Multipurpose bond tester capable of handling up to 500Kgf load test Load fracture measurement precision, ± Achieved 0.15% GUI SW design maximizing user convenience, all-in-one test page Right Joystick button – Test Start key, Left Joystick button – XY stage speed variable, super high/low speed Test speed, shear test height , tool landing speed, overtravel, grade list & test conditions, etc. can be easily set in fine detail
Application of the latest Window-based GUI OS program technology
TCP/IP, SEC/GEM communication function installed as standard.
Test methods based on international semiconductor test regulations (JEDEC, MILS, EIA)
