Capillary
Dou Yee is a premier total industrial solutions provider in worldwide. It has vast experience in static control, micro-contamination control and various specialized tools and materials required in the semiconductor, disk drive, electronic and other precision technology sectors since 1982.
DOU TEE CAPILLARY IS
– Copper / Gold Wire Capillary
– Long Life Capillary
– High U.S. Energy Transfer
– High Wear Resistance
– High Bending Strength
– Low Frictional Coefficient -
Magnetic Collet
STRENGTH
Memory Semiconductor and Fingerprint Sensor Chip Pick up & Attach improves the void phenomenon. The combined role of back metal makes it easier to remove and attach the tool stably by magnetic force, and maintain flatness in the Attach process.
TECHNOLOGY
We are producing stable and high quality products with precise processing of Back Metal and Silicon Rubber with flatness of less than 50μm. -
Pick Up Pad
It is a pick-up tool that is used from molding to singulation test and packaging with minimum physical force with stable vacuum structure as a transporting silicon PAD used for semiconductor back process. We manufacture high-quality products from mold making to various shapes of designs.
-
Silicon Rubber Collet
STRENGTH
It is a soft silicon-based collet that can be applied as a pick-up water target, such as Scratch and Crack. It is manufactured by mold and is easy for mass production.
TECHNOLOGY– It is possible to implement the smallest domestic type Vacuum Hole 80um so that the smallest chip size pick up less than 100um can be done.
– It is optimized for the work which can endure the high temperature and the improvement of sticky phenomenon, and it is possible to extend the life time (life time) by developing the durable material.
– It is possible to implement customizing shapes of various designs Customer development request completion schedule includes sample development, design, mold, product production within 10 days.
-
Unplug Wire
Unplug wire helps decontamination of capillary holes and it is composed of strong tapered wire, which helps to extend the life of capillary and improve the quality.
-
E-Touch Tip
(For N2 KIT)
-
Plastic Collet
STRENGTH
Metal and Silicon It is a medium hardness material and it is a high functional resin with high molecular structure. It is excellent in abrasion resistance, corrosion resistance, heat resistance, chemical stability, insulation, tensile property and is suitable for shape processing.
TECHNOLOGY
Various special design shapes can be processed by precision machining technology and it can be manufactured in a short time according to customer schedule. -
Test Tool
– Ball(Die) shear tool for Dage, Royce, XYZ tech (Size : 1mil ~ 35mils)
– Wire pull test hook (Size : 1mil ~ 35mil) -
Ceramic Collet
STRENGTH
Ceramic material is a non-metallic solid of inorganic compound, and can work reliably in nonconductivity and resistance to electrical properties.
TECHNOLOGY
Vacuum hole processing can be applied to miniature chip pick up applications such as Mini Micro LED. -
Metal Collet
STRENGTH
– Metal has excellent hardness compared to plastic series and has excellent durability, so it can achieve the best life time and precise shape processing.
– Aluminum – Stainless – Tungsten carbide can be selected according to hardness.TECHNOLOGY
According to our own precision processing equipment, it is possible to process various special design shapes by technology. -
Test Tool
DST/BST/WPT
-
Ejector Pin
STRENGTH
The ejector pin is an auxiliary tool for chip pick up attached to the mounting tape and is applied to three kinds of products (general, thin film, small die) suitable for various applications.
TECHNOLOGY
– HISS
– Tungsten Carbide
– PLASTIC -
Epoxy Drum
New MODEL
AD830 / AD8930 / Etc
REPAIR
– In addition to the progress of new production, it is possible to RECYCLING with the current product REPAIR.
– Disassembly, assembly, parts replacement, flatness reset -
Epoxy Pin
STRENGTH
Epoxy adhesive liquid is dotted according to die size to enable stable and fast production speed.
TECHNOLOGY
– It is possible to process various special design shapes by our own precision processing technology, and it is also possible for short-term schedule according to customer’s production request.
– It has processing technology ability of 1pin ~ 24pin multi pin, so it can process ultrafine shape according to customer’s requirement.
